EP-GMSS50 Premium Stainless Steel Worm Reducer — Product Overview
The SSRV and SSVF series address the most common hygienic drive requirement: 316L housing, NSF H1 oil, food-grade compliance. The EP-GMSS50 goes further — for applications where the standard is insufficient. The GMSS box housing has all six faces CNC-machined and electropolished to Ra ≤ 0.8 µm, not just the functional mounting faces. The worm wheel core is 304 stainless steel, eliminating every ferrous internal component. There is no carbon steel anywhere in the housing assembly.
Five mounting positions (A/B/C/D/E), direct IEC motor coupling for frames 63/71/80 IEC, NSF H1 synthetic oil pre-installed, and full CE/ISO 9001/FDA 21 CFR 177 documentation. The correct choice when a BRC Grade AA, FSSC 22000, or pharmaceutical clean-room audit demands the highest possible material and surface standard from every drive component.
EP-GMSS50 Stainless Steel Worm Reducer — Technical Specifications
| 매개변수 | 사양 |
|---|---|
| 주택 | 304 SS box — all 6 faces CNC-machined, electropolished Ra ≤ 0.8 µm |
| 웜 휠 | 12-2 tin-bronze rim, 304 SS core — zero ferrous internal components |
| 웜 샤프트 | Hardened alloy steel, carburised & ground, 55–60 HRC |
| 표면 마감 | Ra ≤ 0.8 µm electropolished — all 6 external faces |
| 매끄럽게 하기 | NSF H1 fully synthetic ISO VG 150, pre-installed |
| 속도 비율 | 7.5–100:1 |
| 설치 | 5 positions: A / B / C / D / E |
| 출력 옵션 | A single shaft, B double shaft, D output flange, E torque arm |
| IEC Motor Frames | 63/71/80 IEC |
| 파워 레인지 | 0.12–0.37 kW |
| 인증 | CE, ISO 9001, FDA 21 CFR 177, EHEDG 호환 |
| Ambient Temperature | -20°C ~ +50°C 표준 |
| Surface Comparison | All 6 faces machined (vs functional-only on SSRV/SSVF); 304 SS wheel core (vs carbon steel on SSRV/SSVF) |
EP-GMSS50 Premium Stainless Steel Worm Reducer — Core Features
■ All 6 Faces CNC-Machined — Ra ≤ 0.8 µm Electropolished
The EP-GMSS50 housing is machined on every face to Ra ≤ 0.8 µm and electropolished — not just the mounting and output faces. No rough casting surfaces anywhere on the external housing — no contamination traps, no paint or coating to flake into product zones.
■ 304 SS Worm Wheel Core — Zero Ferrous Internal Components
The worm wheel uses a 12-2 tin-bronze rim bonded to a 304 stainless steel core. Combined with the 304 SS box housing, this eliminates every ferrous component from the housing assembly — the defining difference between GMSS and the standard SSRV/SSVF series.
■ 5 Mounting Positions A/B/C/D/E — No Modification Required
Full 5-position mounting flexibility in a single product — horizontal, output-up, output-down, input-up, and torque-arm shaft-mount. One GMSS unit fits every installation orientation on an OEM machine without modification.
■ NSF H1 Synthetic Oil Pre-Installed — No Commissioning Oil Change
Ships with NSF H1 registered ISO VG 150 synthetic lubricant. No oil change at commissioning. 5,000-hour initial service interval under standard food plant conditions — reducing planned maintenance interventions.
■ FDA 21 CFR 177 + EHEDG — Audit-Ready Documentation
Material certificates, NSF H1 oil certification, CE declaration, and FDA 21 CFR 177 compliance documentation supplied with every unit. The complete documentation package for IQ/OQ/PQ pharmaceutical validation or food safety management system qualification.
■ IEC 63/71/80 IEC — Direct Motor Coupling
Compatible with 63/71/80 IEC IEC motor frames via standard PAM B5 and B14 adaptors. All five mounting positions supported with the same motor coupling hardware.
EP-GMSS50 Premium Stainless Steel Worm Reducer — Industry Applications
⚔ BRC / FSSC 22000 Grade A Food Manufacturing
The EP-GMSS50’s Ra ≤ 0.8 µm all-face finish, zero ferrous internals, and NSF H1 oil satisfy the most stringent BRC Grade AA and FSSC 22000 certification requirements for food contact zone drive equipment — where SSRV or aluminium reducers do not pass visual inspection.
☵ Pharmaceutical Clean-Room and GMP Drives
The GMSS provides the material documentation trail required for pharmaceutical clean-room equipment qualification. 304 SS material certs, FDA 21 CFR 177 compliance, NSF H1 oil cert, and CE declaration in the equipment file on day one.
⚒ Premium Food Export Equipment
Food processing equipment exported to markets with the highest hygienic standards — EU, Japan, Australia, North America — specifies GMSS to meet premium retailer supply chain audit requirements that standard stainless reducers do not satisfy.
⚛ Laboratory & Precision Instrument Drives
Laboratory and precision analytical instrument drives requiring zero ferrous contamination risk, premium surface finish, and compact 5-position mounting in a single standardised product use GMSS for consistent specification across all instrument positions.
Ever Power Manufacturing Quality — EP-GMSS50 Stainless Steel Worm Reducer
■ 316L / 304 스테인리스강 — 재질 인증서 제공
모든 EP 스테인리스강 웜 감속기는 하우징 합금(지정된 대로 316L 또는 304)에 대한 재료 시험 인증서와 함께 출고됩니다. 인장 강도, 연신율 및 내식성은 EN 10088에 따라 검증되었습니다.
■ CE 마크 + ISO 9001 + FDA 21 CFR 177 준수
EU 기계류 지침에 따른 CE 마크를 획득했습니다. ISO 9001:2000 인증을 받은 생산 시설입니다. 하우징 자재는 식품과의 우발적 접촉에 대한 FDA 21 CFR 177.1550 규정을 준수하며, HACCP 심사원들의 승인을 받았습니다.
■ 출하 전 소음, 누출 및 토크 테스트
모든 제품은 정격 부하 시 소음이 65dB(A) 미만(합성 윤활유 사용으로 주철 제품보다 조용함), 30분 가압 누출 테스트, 출력 토크가 ±5% 이내인 기준을 통과했습니다.
■ EHEDG 호환 설계
매끄러운 외부 표면, 제품 접촉 부위에 외부 고정 장치 없음, CIP/SIP 세척을 위한 밀봉 구조. 유럽 위생 엔지니어링 및 설계 그룹(EHEDG)의 위생 장비 설계 지침을 준수합니다.
EP-GMSS50 Premium Stainless Steel Worm Reducer — Customer Reviews
“EP-GMSS chosen for our BRC Grade AA certified bakery. All 6 faces CNC-machined SS — passes the most stringent visual hygiene inspection. NSF H1 oil already installed. Zero issues after 2 years on our mixing line.”
“GMSS on our pharmaceutical clean-room conveyor drives. 304 SS box with Ra ≤ 0.8 µm finish — swab test results consistently below detection limit. FDA 21 CFR 177 certs in the batch record on day one.”
“Used GMSS on export-grade dairy equipment. Premium appearance — all six faces mirror-polished. Client’s FSSC 22000 audit passed without a single drive-related finding for three consecutive years.”
“Outstanding quality box-style stainless reducer. GMSS63 drives our confectionery enrober. The 5-position mounting flexibility let us fit the same unit at different line positions without modification.”
